Magnet for injection moulding machine hopper (temperature resistance up to 80 °C) dia. 350 mm
50484
Out of stock
Price
€1,038.45/pcTax excluded
0 items0€0.00
To obtain your FREE TRANSPORT, you have to purchase in a value of €1,000.00
Magnet for injection moulding machine hopper MDN 250 MVM-EKO
This separator not suit you? We will make a custom separator for you |
Contact us  Customer support |
| Make an inquiry |
Data sheet
| Diameter (mm) | 250 |
| Material | Stainless steel |
| Temperature resistance | 80 °C |
| Marking | MDN 250 MVM-EKO |
| Weight (kg) | 2,5 |
Attachments
In Stock
We'll send tomorrow
Doprava nad 1000 Kč ZDARMA
Additional description
Magnet to be used in injection molding machine hoppers is designed for a separation of ferromagnetic impurities from dry mixtures characterized by good loose parameters.
The device contains 5 rods; neodymium magnets are included.
Magnet to be used with injection molding machine hoppers is manufactured using DIN 1.4301 stainless steel.
Magnetic induction on the coat is 4600 G; coat tear-off force is 60 N.
Magnetic separator body is surface-treated by polishing.
Maximum working temperature of this separator is 80 °C, total weight is 2.5 kg.
The device contains 5 rods; neodymium magnets are included.
Magnet to be used with injection molding machine hoppers is manufactured using DIN 1.4301 stainless steel.
Magnetic induction on the coat is 4600 G; coat tear-off force is 60 N.
Magnetic separator body is surface-treated by polishing.
Maximum working temperature of this separator is 80 °C, total weight is 2.5 kg.
For more information please see: www.magnetic-separators.info (It will open in a new window)
