Magnetic sweeper for cleaning carriers MM 1800 DM F-MODEL 1
52448
Out of stock
Price
€1,832.00Tax excluded
0 items0€0.00
To obtain your FREE TRANSPORT, you have to purchase in a value of €1,000.00
Magnetic sweeper for cleaning carriers MM 800 DM-UP F
This separator not suit you? We will make a custom separator for you |
Contact us  Customer support |
| Make an inquiry |
Data sheet
| Material | Stainless steel DIN 1.4301, EN 10088, ČSN 17240, AISI 304, AKV 7 - non-stabilized austenitic nickel-chromium steel (X5CrNi 18-10) |
| Surface treatment | Glass bead blasting |
| Total weight | 25 kg |
| Product state | New |
| Design | UP |
| Magnet type | Ferrite |
| Temperature resistance | 200 °C (maximum operating temperature 80 °C) |
| Magnetic surface width | 80 mm |
| Magnetic surface length | 800 mm |
Videos
Additional description
| MM 1800 DM F-MODEL 1 52448 |
Distance from the surface |
||
| 30 mm | 50 mm | 80 mm | |
| Lifted object | Collection success rate | ||
| Small office clip (0,3 g) | 100 % | 100 % | 80 % |
| Steel splinter (1,4 g) | 100 % | 100 % | 0 % |
| Self-tapping screw 4x60 (2,8 g) | 100 % | 100 % | 70 % |
| Self-tapping screw 5x80 (6 g) | 100 % | 100 % | 40 % |
| Pad 5 (0,3 g)) | 100 % | 100 % | 0 % |
| Pad 8 (1,5 g) | 100 % | 90 % | 0 % |
| Pad 10 (2,9 g) | 100 % | 90 % | 0 % |
| Nut M5 (1,1 g) | 100 % | 30 % | 0 % |
| Nut M8 (4,6 g) | 100 % | 10 % | 0 % |
| Nut M10 (10 g) | 100 % | 10 % | 0 % |
| Screw M6x10 (4 g) | 100 % | 10 % | 0 % |
| Screw M8x20 (11,8 g) | 100 % | 50 % | 0 % |
| Screw M10x55 (37,4 g) | 100 % | 60 % | 0 % |
